FREQUENCY

(MHz)

CONVERSION LOSS

(dB)

LO-RF ISOLATION

(dB)

LO-IF ISOLATION

(dB)

IP3

at center

band

(dBm)

LO/RF

IF

Mid-Band

m

Total

Range

Max.

L

M

U

L

M

U

f

—

X

σ

Max.

Typ. Min.

Typ. Min.

Typ. Min.

Typ. Min.

Typ. Min.

Typ. Min.

Typ.

10-1000

DC-800

7.0

0.10

70 55

60 43

47 37

45 32

35 25

26 17

16

L = low range [f

M = mid range [10 f

U = upper range [f

m= mid band [2f

1 dB COMP.: +5 dBm typ.

†

Conversion loss increases 0.5 when IF is above150 MHz

ISO 9001 ISO 14001 CERTIFIED

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site

The Design Engineers Search Engine Provides ACTUAL Data Instantly From MINI-CIRCUITS At: www.minicircuits.com

RF/IF MICROWAVE COMPONENTS

minicircuits.com

ALL NE

W

Page 1 of 2

PCB Land Pattern

Suggested Layout,

Tolerance to be within ±.002

Level 10 (LO Power +10 dBm) 10 to 1000 MHz

High Reliability Mixer

Surface Mount

Demo Board MCL P/N: TB-03

Suggested PCB Layout (PL-052)

Outline Dimensions (

)

inch

mm

Maximum Ratings

Pin Connections

LO

6

RF

3

IF

2

GROUND

1,4,5

Outline Drawing

Electrical Specifications

REV. OR

M109914

ADEX-R10LH+

ED-12873/5

WL/TD/QL

070516

A

B

C

D

E

F

G

.272

.310

.220

.100

.112

.055

.100

6.91

7.87

5.59

2.54

2.84

1.40

2.54

H

J

K

L

wt

.030

.026

.065

.300

grams

0.76

0.66

1.65

7.62

0.20

Typical Performance Data

Electrical Schematic

Operating Temperature

-40°C to 85°C

Storage Temperature

-55°C to 100°C

RF Power

50mW

IF Current

40mA

Features

• hermetically sealed ceramic quad

• low conversion loss, 7.0 dB typ.

• excellent L-R isolation, 60 dB typ.

• good VSWR, 1:8:1 typ. for LO,

1.5:1 typ. for RF, 1.5:1 typ. for IF

• good performance to 1500 MHz

• low profile package

• aqueous washable

• protected by US Patent 6,133,525 and 6,947,717

Applications

• cellular

• instrumentation

• VHF/UHF receivers

Frequency

(MHz)

Conversion

Loss

(dB)

Isolation

L-R

(dB)

Isolation

L-I

(dB)

VSWR

RF Port

(:1)

VSWR

LO Port

(:1)

RF

LO

LO

+10dBm

LO

+10dBm

LO

+10dBm

LO

+10dBm

LO

+10dBm

ADEX-R10LH+

CASE STYLE: CD542

PRICE: $3.35 ea. QTY. (10-49)

+ RoHS compliant in accordance

with EU Directive (2002/95/EC)

The +Suffix has been added in order to identify RoHS

Compliance. See our web site for RoHS Compliance

methodologies and qualifications.
