FEED THROUGH STANDOFF

FEET EUROSTRIPS

Panel Mount

For wire-to-wire connections in

HVAC, appliance, equipment,

power distribution and other

industrial applications with

restricted budget and space

requirements.

Easy to use feed through termi-

nal strips are a cost-effective

alternative to barrier strips or

other types of terminal blocks.

Simply strip the wire, insert,

and tighten the screw.

Eurostrips feature tubular

screw clamps, with wire protec-

tors, and recessed metal parts

for finger protection. The stain-

less steel wire protectors exhib-

it excellent memory and the

most effective connection.

Eurostrips described on this

and the preceeding page are

available with standoff feet for

increased wiring efficiency.

They can be panel mounted or

left to free float. Offered in easy

to cut 12 pole strips, they can

also be ordered precut with the

required number of poles.

• Tubular screw clamp

• Panel mount or free float

• Housing material:

polyamide 6.6

• Color: opaque white

• Marking plates or

factory imprinted

10 mm

3.6 mm

6 mm

2.5-4 mm2

24-10 AWG

400 V

600 V

10 A

30 A

0.8 Nm

7.0 lb-in

Cat. No.

Std. Pk.

HE4HNWPR/02

100

HE4HNWPR/03

100

HE4HNWPR/04

100

HE4HNWPR/05

100

HE4HNWPR/06

HE4HNWPR/07

HE4HNWPR/08

HE4HNWPR/09

HE4HNWPR/10

HE4HNWPR/11

HE4HNWPR/12

HE1H

HE4HN

Pole Spacing

Mounting Hole Diameter

Stripping Length

Approvals

Wire Range

Voltage Rating

Current Rating

Torque

No. of Poles

Standoff feet with wire protector

Dimensions mm

A= 8.0

I= 6.6

B= M2.6

J= 6.5

C= 5.2

K= 10.3

D= 2.8

L= 94 (12 pole)

E= Ø3

M= 16

F= Ø5

N =

16.2

G = 8.0

O= 10.1

H= Ø2.8

Dimensions mm

A= 10.0

I= 6.7

B= M3

J= 8.5

C= 6.4

K= 12.1

D= 3.5

L= 117 (12 pole)

E= Ø3.6

M= 19.1

F= Ø5.7

N =

G = 10.0

O =

14.0

H= Ø3.6

8 mm

3 mm

5 mm

1-2.5 mm2

24-12 AWG

400 V

600 V

6 A

20 A

0.5 Nm

4.4 lb-in

Cat. No.

Std. Pk.

HE1HWPR/02

100

HE1HWPR/03

100

HE1HWPR/04

100

HE1HWPR/05

100

HE1HWPR/06

HE1HWPR/07

HE1HWPR/08

HE1HWPR/09

HE1HWPR/10

HE1HWPR/11

HE1HWPR/12

Altech Corp.® • 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490 • www.altechcorp.com

E211022
