TMMDB3

4/4

PACKAGE MECHANICAL DATA (in millimeters)

MINIMELF

REF.

DIMENSIONS

Millimeters

Inches

Min.

Typ.

Max.

Min.

Typ.

Max.

A

3.30

3.40

3.6

0.130

0.134

0.142

B

1.59

1.60

1.62

0.063

0.063

0.064

C

0.40

0.45

0.50

0.016

0.018

0.020

D

1.50

0.059

B

O

/

A

C

C

D

O

/

0.05 E-F

O

/

F

E

Information furnished is believed to be accurate and reliable. However, STMicroelectronics assumes no responsibility for the consequences of

use of such information nor for any infringement of patents or other rights of third parties which may result from its use. No license is granted by

implication or otherwise under any patent or patent rights of STMicroelectronics. Specifications mentioned in this publication are subject to

change without notice. This publication supersedes and replaces all information previously supplied.

STMicroelectronics products are not authorized for use as critical components in life support devices or systems without express written ap-

proval of STMicroelectronics.

The ST logo is a registered trademark of STMicroelectronics

© 2001 STMicroelectronics - Printed in Italy - All rights reserved.

STMicroelectronics GROUP OF COMPANIES

Australia - Brazil - China - Finland - France - Germany - Hong Kong - India - Italy - Japan - Malaysia

Malta - Morocco - Singapore - Spain - Sweden - Switzerland - United Kingdom - U.S.A.

http://www.st.com

2.5

5

2

FOOTPRINT

10

20

50

100

200

500

0

5

10

15

20

25

30

35

40

C(nF)

tp(µs)

Tj=25°C

0

Ω

10

Ω

22

Ω

68

Ω

47

Ω

33

Ω

Fig. 3: Time duration while current pulse is higher

50mA versus C and Rs (typical values).
