TDA9113

21/50

Note 48: For any H and V correction component of the waveforms on EWOut and VOut pins and for internal waveform

for corrections of H asymmetry, displayed in the table, weight of the other relevant components is nullified

(minimum for parabola, S-correction, medium for keystone, all corner corrections, C-correction, parallelogram,

parabola asymmetry correction, written in corresponding registers).

Parallelogram

correction

12h

x0000000

x1111111

Pin cushion

asymmetry

correction

11h

x0000000

x1111111

Vertical

dynamic

correction

amplitude

15h

VDyCor

01111111

Application dependent

x0000000

11111111

HDyCor

horizontal

adjustments

HDyCor

See Figure 14 on page 36

Application dependent

Function

Sad

Byte

Waveform

Effect on Screen

tParalC(min)

static phase

tVR

1/2TVR

TVR

tParalC(max)

static phase

tVR

1/2TVR

TVR

tVR

1/2TVR

TVR

tPCAC(max)

static

H-phase

tVR

1/2TVR

TVR

tPCAC(max)

static

H-phase

tVR

1/2TVR

TVR

VVD-V(max)

VVD-DC

VDyCorP

tVR

1/2TVR

TVR

VVD-V(max)

VVD-DC

tVR

1/2TVR

TVR

VVD-V(max)

VVD-DC

VDyCorP
