295 / 1504 page ![]() Section 9 Bus Controller (BSC) Rev. 2.00 Sep. 24, 2008 Page 263 of 1468 REJ09B0412-0200 9.7.6 Read Strobe ( RD) When the byte control SRAM space is specified, the RDNCR setting for the corresponding space is invalid. The read strobe negation timing is the same timing as when RDNn = 1 in the basic bus interface. Note that the RD timing with respect to the DACK and EDACK rising edge becomes different. 9.7.7 Extension of Chip Select ( CS) Assertion Period In the byte control SRAM interface, the extension cycles can be inserted before and after the bus cycle in the same way as the basic bus interface. For details, refer to section 9.6.6, Extension of Chip Select ( CS) Assertion Period. 9.7.8 DACK and EDACK Signal Output Timing For DMAC or EXDMAC single address transfers, the DACK and EDACK signal assert timing can be modified by using the DKC and EDKC bits in BCR1. Figure 9.28 shows the DACK and EDACK signal output timing. Setting the DKC bit or the EDKC bit to 1 asserts the DACK or EDACK signal a half cycle earlier. |
|
