Section 14 16-Bit Timer Pulse Unit (TPU)

Rev. 2.00 Sep. 24, 2008 Page 723 of 1468

REJ09B0412-0200

Bit

Bit Name

Initial

value

R/W

Description

TGIED

R/W

TGR Interrupt Enable D

Enables/disables interrupt requests (TGID) by the TGFD bit

when the TGFD bit in TSR is set to 1 in channels 0 and 3.

In channels 1, 2, 4, and 5, bit 3 is reserved. It is always read as

0 and cannot be modified.

0: Interrupt requests (TGID) by TGFD bit disabled

1: Interrupt requests (TGID) by TGFD bit enabled

TGIEC

R/W

TGR Interrupt Enable C

Enables/disables interrupt requests (TGIC) by the TGFC bit

when the TGFC bit in TSR is set to 1 in channels 0 and 3.

In channels 1, 2, 4, and 5, bit 2 is reserved. It is always read as

0 and cannot be modified.

0: Interrupt requests (TGIC) by TGFC bit disabled

1: Interrupt requests (TGIC) by TGFC bit enabled

TGIEB

R/W

TGR Interrupt Enable B

Enables/disables interrupt requests (TGIB) by the TGFB bit

when the TGFB bit in TSR is set to 1.

0: Interrupt requests (TGIB) by TGFB bit disabled

1: Interrupt requests (TGIB) by TGFB bit enabled

TGIEA

R/W

TGR Interrupt Enable A

Enables/disables interrupt requests (TGIA) by the TGFA bit

when the TGFA bit in TSR is set to 1.

0: Interrupt requests (TGIA) by TGFA bit disabled

1: Interrupt requests (TGIA) by TGFA bit enabled

Note:

The bit 7 in TIER of unit 1 is a reserved bit. This bit is always read as 0 and the initial

value should not be changed.

14.3.5

Timer Status Register (TSR)

TSR indicates the status of each channel. The TPU has six TSR registers, one for each channel.

Bit

Bit Name

Initial Value

R/W

TCFD



TCFU

R/(W)*

TCFV

R/(W)*

TGFD

R/(W)*

TGFC

R/(W)*

TGFB

R/(W)*

TGFA

R/(W)*

Note: * Only 0 can be written to bits 5 to 0, to clear flags.
