Section 13 I/O Ports

Rev. 2.00 Sep. 24, 2008 Page 643 of 1468

REJ09B0412-0200

13.2.14

Port J

The pin function of port J can be switched with that of port D according to the combination of

operating mode, the EXPE bit, and the PCJKE bit settings. The pin function of port J can be

switched according to the PCJKE bit setting in the single-chip mode (EXPE = 0). However, do not

change the setting of the PCJKE bit in external extended mode. For details, see section 13.3.12,

Port Function Control Register D (PFCRD).

(1)

PJ7/TIOCA8/TIOCB8/TCLKH/PO23

The pin function is switched as shown below according to the combination of register setting of

PPG and TPU, setting of the port function control register (PFCR), and the PJ7DDR bit settings.

Setting

PPG

TPU

I/O Port

Module Name

Pin Function

PO23_OE

TIOCB8_OE

PJ7DDR

PPG

PO23 output*



TPU

TIOCB8 output*



PJ7 output*

I/O port

PJ7 input*

Note:

Valid when PCJKE = 1.

(2)

PJ6/TIOCA8/PO22

The pin function is switched as shown below according to the combination of register setting of

PPG and TPU, setting of the port function control register (PFCR), and the PJ6DDR bit settings.

Setting

PPG

TPU

I/O Port

Module Name

Pin Function

PO22_OE

TIOCA8_OE

PJ6DDR

PPG

PO22 output*



TPU

TIOCA8 output*



PJ6 output*

I/O port

PJ6 input*

Note:

Valid when PCJKE = 1.
