Section 11 EXDMA Controller (EXDMAC)
Rev. 2.00 Sep. 24, 2008 Page 459 of 1468
REJ09B0412-0200
11.3.1
EXDMA Source Address Register (EDSAR)
EDSAR is a 32-bit readable/writable register that specifies the transfer source address. An address
update function is provided that updates the register contents to the next transfer source address
each time transfer processing is performed. In single address mode, the EDSAR value is ignored
when the address specified by EDDAR is transferred as a destination address (DIRS = 1 in
EDACR).
EDSAR can be read at all times by the CPU. When reading EDSAR for a channel on which
EXDMA transfer processing is in progress, a longword-size read must be executed. Do not write
to EDSAR for a channel on which EXDMA transfer is in progress.
31
0
R/W
30
0
R/W
29
0
R/W
28
0
R/W
27
0
R/W
24
0
R/W
26
0
R/W
25
0
R/W
Bit
Bit Name
Initial Value
R/W
23
0
R/W
22
0
R/W
21
0
R/W
20
0
R/W
19
0
R/W
16
0
R/W
18
0
R/W
17
0
R/W
Bit
Bit Name
Initial Value
R/W
15
0
R/W
14
0
R/W
13
0
R/W
12
0
R/W
11
0
R/W
8
0
R/W
10
0
R/W
9
0
R/W
Bit
Bit Name
Initial Value
R/W
7
0
R/W
6
0
R/W
5
0
R/W
4
0
R/W
3
0
R/W
0
0
R/W
2
0
R/W
1
0
R/W
Bit
Bit Name
Initial Value
R/W
