Section 9 Bus Controller (BSC)

Rev. 2.00 Sep. 24, 2008 Page 233 of 1468

REJ09B0412-0200

(4)

Number of Access Cycles

(a)

Basic Bus Interface

The number of access cycles in the basic bus interface can be specified as two or three cycles by

the ASTCR. An area specified as 2-state access is specified as 2-state access space; an area

specified as 3-state access is specified as 3-state access space.

For the 2-state access space, a wait cycle insertion is disabled. For the 3-state access space, a

program wait (0 to 7 cycles) specified by WTCRA and WTCRB or an external wait by

WAIT can

be inserted.

Assertion period of the chip select signal can be extended by CSACR.

Number of access cycles in the basic bus interface

= number of basic cycles (2, 3) + number of program wait cycles (0 to 7)

+ number of

CS extension cycles (0, 1, 2)

[+ number of external wait cycles by the

WAIT pin]

(b)

Byte Control SRAM Interface

The number of access cycles in the byte control SRAM interface is the same as that in the basic

bus interface.

Number of access cycles in byte control SRAM interface

= number of basic cycles (2, 3) + number of program wait cycles (0 to 7)

+ number of

CS extension cycles (0, 1, 2)

[+ number of external wait cycles by the

WAIT pin]

(c)

Burst ROM Interface

The number of access cycles at full access in the burst ROM interface is the same as that in the

basic bus interface. The number of access cycles in the burst access can be specified as one to

eight cycles by the BSTS bit in BROMCR.

Number of access cycles in the burst ROM interface

= number of basic cycles (2, 3) + number of program wait cycles (0 to 7)

+ number of

CS extension cycles (0, 1)

[+number of external wait cycles by the

WAIT pin]

+ number of burst access cycles (1 to 8)

× number of burst accesses (0 to 63)
