1116 / 1158 page ![]() Section 25 Electrical Characteristics Rev.1.00 Jun. 07, 2006 Page 1064 of 1102 REJ09B0294-0100 B φ A23 to A0 LUCAS, LLCAS LUCAS, LLCAS Read Write Note: Timming of DACK when DDS = 0 and EDDS = 0 Timming of RAS when RAST = 0 Tcw is a wait cycle inserted by the programmable wait Tcwp is a wait cycle inserted by the pin wait Tp Tr Tc1 Tpw Ttw Tc2 RAS OE, RD WE D15 to D0 OE, RD WE tWTS tWTH tWTS tWTH D15 to D0 AS WAIT BS RD/ WR RD/ WR (DKC = 0) DACK3 to DACK0 (DKC = 1) DACK3 to DACK0 Figure 25.20 DRAM Access Timing: Two-State Access, One Wait |
|
