1094 / 1158 page ![]() Section 25 Electrical Characteristics Rev.1.00 Jun. 07, 2006 Page 1042 of 1102 REJ09B0294-0100 Item Symbol Min. Typ. Max. Unit Test Conditions Vcc start voltage* 7 V CCSTART 0.8 V Vcc rising gradient* 7 SV CC 20 ms/V Notes: 1. When the A/D and D/A converters are not used, the AV CC, Vref, and AVSS pins should not be open. Connect the AV CC and Vref pins to VCC, and the AVSS pin to VSS. 2. The case where port 5 is used as IRQ0 to IRQ7. 3. Current consumption values are for V IHmin = VCC – 0.5 V and VILmax = 0.5 V with all output pins unloaded and all input pull-up MOSs in the off state. 4. The values are for V RAM ≤ VCC < 3.0 V, VIHmin = VCC × 0.9, and VILmax = 0.3 V. 5. I CC depends on f as follows: I CCmax = 35 (mA) + 1.8 (mA/MHz) × f (normal operation) I CCmax = 30 (mA) + 1.2 (mA/MHz) × f (sleep mode) 6. The values are for reference. 7. This can be applied when the RES pin is held low at power-on. Table 25.3 Permissible Output Currents Conditions: V CC = PLLVCC = DrVCC = 3.0 V to 3.6 V, AVCC = 3.0 V to 3.6 V, Vref = 3.0 V to AVCC, V SS = PLLVSS = DrVSS = AVSS = 0 V*, Ta = –20°C to +75°C (regular specifications), T a = –40°C to +85°C (wide-range specifications) Item Symbol Min. Typ. Max. Unit Permissible output low current (per pin) Output pins except port 3 I OL 2.0 mA Permissible output low current (per pin) Port 3 I OL 10 mA Permissible output low current (total) Total of all output pins ΣI OL 80 mA Permissible output high current (per pin) All output pins –I OH 2.0 mA Permissible output high current (total) Total of all output pins Σ–I OH 40 mA Caution: To protect the LSI's reliability, do not exceed the output current values in table 25.3. Note: * When the A/D and D/A converters are not used, the AV CC, Vref, and AVSS pins should not be open. Connect the AV CC and Vref pins to VCC, and the AVSS pin to VSS. |
|
