Section 15 Serial Communication Interface (SCI, IrDA, CRC)

Rev.1.00 Jun. 07, 2006 Page 659 of 1102

REJ09B0294-0100

15.3

The SCI has the following registers. Some bits in the serial mode register (SMR), serial status

modes

normal serial communication interface mode and smart card interface mode; therefore,

the bits are described separately for each mode in the corresponding register sections.

Channel 0:

• Receive shift register_0 (RSR_0)

• Transmit shift register_0 (TSR_0)

• Receive data register_0 (RDR_0)

• Transmit data register_0 (TDR_0)

• Serial mode register_0 (SMR_0)

• Serial control register_0 (SCR_0)

• Serial status register_0 (SSR_0)

• Smart card mode register_0 (SCMR_0)

• Bit rate register_0 (BRR_0)

Channel 1:

• Receive shift register_1 (RSR_1)

• Transmit shift register_1 (TSR_1)

• Receive data register_1 (RDR_1)

• Transmit data register_1 (TDR_1)

• Serial mode register_1 (SMR_1)

• Serial control register_1 (SCR_1)

• Serial status register_1 (SSR_1)

• Smart card mode register_1 (SCMR_1)

• Bit rate register_1 (BRR_1)
