STRAP OPTION

12/55

Issue 1.1

2.1 STRAP OPTION REGISTER DESCRIPTION

2.1.1 STRAP REGISTER 0 INDEX 4AH (STRAP0)

Bits 7-0, This register reflect the status of pins MD[7:0] respectively. They are expected to be connected

on the system board to the SIMM configuration pins as follows:

Note that the SIMM speed and type information read here is meant only for the software and is not used

by the hardware. The software must program the Host and graphics DRAM controller configuration regis-

ters appropriately based on these bits.

This register defaults to the values sampled on MD[7:0] pins after reset.

MD 39

Reserved

Pull up

MD 40

PCMCIA or PCI i/f

3C,bit 0

User defined

PCI

PCMCIA

MD 41

Local Bus or ISA i/f

3C,bit 1

User defined

ISA

Local Bus

MD 42

Key Board & Mouse

3C,bit 2

User defined

External

Internal

MD 43

Parallel Port

3C,bit 3

User defined

External

Internal

MD 44

Serial Port

UART1

3C,bit 4

User defined

External

Internal

MD 45

UART2

3C,bit 5

User defined

External

Internal

MD 46

Reserved

3C,bit 6

Pull down

MD 47

Reserved

3C,bit 7

Pull down

MD 48

TFT

Outputs on RFU pads

3D,bit 0

User defined

Disable

Enable

MD 49

Cardbus Socket

5V Availability

3D,bit 1

User defined

Not Availa-

ble

Available

MD 50

3.3V Availability

3D,bit 2

User defined

Not Availa-

ble

Available

MD 51

x.xV Available

3D,bit 3

User defined

Not Availa-

ble

Available

MD 52

y.yV Available

3D,bit 4

User defined

Not Availa-

ble

Available

MD 53

Reserved

Pull uo

MD 56

Reserved

Pull up

MD 57

Reserved

Pull down

MD 58

Reserved

Pull up

MD 59

Reserved

Pull down

Bit Sampled

Description

Bit 7

SIMM 0 DRAM type

Bits 6-5

SIMM 0 speed

Bit 4

SIMM 1 DRAM type

Bits 3-2

SIMM 1 speed

Bits 1-0

Reserved

Memory

Data

Lines

Refer to

Designation

Location

Actual

Settings

Set to ’0’

Set to ’1’
