STLS2F02

Electrical characteristics

41/49

Table 19.

Input setup and hold time

(Test conditions:SYSCLK=100 MHz, PCICLK=66 MHz, CoreClk=1000 MHz)

Parameter

Min

Typ

Max

Unit

PCI_* signals setup time

3.0

PCI_* signals hold time

0.0

LIO_* signals setup time

3.0

LIO_* signals hold time

0.0

Table 20.

Output delay time

(Test conditions:SYSCLK=100 MHz, PCICLK=133 MHz, CoreClk=1000 MHz)

Parameter

Min

Typ

Max

Unit

PCI_* signals effective delay

0.7

3.8

LIO_* signals effective delay

1.5

6.0

DDDR2_A*/RAS*/CAS*/WE*/CS*/CKE*/ODT*

signals effective delay

1.5

DDR2_DQ*/DQM* effective delay

0.75

Table 21.

JTAG parameters

(Test condition:TCK=100 MHz)

Parameter

Min

Typ

Max

Unit

TCK high level time

TCK low level time

TCK rising time

TCK falling time

TRST pulse width

TDI,TMS setup time

3.5

4.4

TDI,TMS hold time

2.5

5.5

TDO output effective delay

1.28

TDO output disable delay

1.28
