Rev. A/JJ 2007-06-15

RL101F – RL107F

1.0A FAST

RECOVERY RECTIFIER

TAITRON COMPONENTS INCORPORATED www.taitroncomponents.com

Page 1 of 6

Tel:

(800)-TAITRON (800)-824-8766 (661)-257-6060

Fax:

(800)-TAITFA

(800)-824-8329 (661)-257-6415

1.0A Fast Recovery Rectifier

Features

• Low Forward Voltage Drop

• High Current Capability

• High Surge Current Capability

• High Reliability

• RoHS compliant

Mechanical Data

Case:

Molded Plastic

Epoxy:

Meets UL 94V-0 flammability rating

Terminals:

Axial leads, solderable per MIL-STD-202, Method 208

Polarity:

Cathode indicated by color band

Weight:

0.008 Ounce, 0.22 gram

Maximum Ratings (T

Ambient=25ºC unless noted otherwise)

Electrical Characteristics (T

Ambient=25ºC unless noted otherwise)

Symbol

Description

RL101F

RL102F

RL103F

RL104F

RL105F

RL106F

RL107F

Unit

VRRM

Maximum Repetitive

Peak Reverse Voltage

50

100

200

400

600

800

1000

V

VRMS

Maximum RMS Voltage

35

70

140

280

420

560

700

V

VDC

Maximum DC Blocking

Voltage

50

100

200

400

600

800

1000

V

IO(AV)

Maximum Average

Forward Rectified

Current @Ta=75° C

1.0

A

IFSM

Peak Forward Surge

Current (Note1)

50

A

TJ

Operating Junction

Temperature Range

-55 to +150

° C

TSTG

Storage Temperature

Range

-55 to +150

° C

A-405
