HALT

Suspend on HALT.

HALT = 0:

CPU does not enter suspend mode following execution of a HLT instruction

HALT = 1:

CPU enters suspend mode following execution of a HLT instruction.

SUSP

Enable Suspend Pins.

SUSP = 0:

SUSP# input is ignored and SUSPA# output floats.

SUSP = 1:

SUSP# input and SUSPA# output are enabled.

Reg. INDEX = C2h

654

SUSP

BWRT

BARB

WT1

HALT

LOCK-NW

WBAK

COP/Reserved

Table 2 - 2

CCR2

Reg. INDEX = C3h

654

NMIEN

SMI-LOCK

Reserved

Table 2 - 1

CCR3

ST486DX - SMM IMPLEMENTATION

SMI_LOCK SMM Register Lock.

SMI_LOCK = 0: Any program in normal mode, as well as SMM software, has access to all

Configuration Control Registers.

SMI_LOCK = 1: The following Configuration Control Register bits can not be modified unless

operating in SMM mode:

SMI, SMAC, MMAC, NMIEN, SMI_LOCK, and SMAR register size fields.

NMIEN

NMI Enable.

NMIEN = 0:

NMI (Non-Maskable Interrupt) is not recognized during SMM. One occurrence of

NMI is latched and serviced after SMM mode is exited. The NMIEN bit should

be cleared before executing a RSM instruction to exit SMM.

NMIEN = 1:

NMI is enabled during SMM. This bit should only be set temporarily while in the

SMM routine to allow NMI interrupts to be serviced. NMIEN should not be set
