3.0A Sintered Glass Passivated Ultra Fast Rectifier

Rev. A/AH 2007-11-07

UGF3AB – UGF3MB

www.taitroncomponents.com

Page 2 of 4

Fig.1- Forward Current Derating Curve

Ambient Temperature (°C)

Fig.2-Max. Non-Repetitive Peak Forward Surge Current

Number of Cycles at 60Hz

Note: Thermal resistance from junction to ambient and from junction to lead P.C.B mounted on 0.2x0.2”

(5.0x5.0mm) copper pad areas.

Typical Characteristics Curves

Symbol

Description

UGF3

Unit

Conditions

Maximum

Instantaneous

Forward Voltage

1.0

1.25

1.7

IF=1.0A

TA=25° C

120

TA=125° C

Maximum DC Reverse

Current at Rated DC

Blocking Voltage

120

µA

TA=150° C

Trr

Maximum Reverse

Recovery Time

IF=0.5A, IR=1.0A,

Irr=0.25A

Typical Junction

Capacitance

VR=4V, f=1MHz

RthJA

RthJL

Typical Thermal

Resistance

°C / W

Note

TJ,

TSTG

Operating Junction

and Storage

Temperature Range

-65 to +175

° C
