Important Information and Precautions

z PowerStars, when powered up, are very bright. Thus it is advised that you do not look directly at it. Turn the

PowerStar away from you and do not shine into the eyes of others.

z Do not operate PowerStar with a Power Supply with unlimited current. Connection to constant voltage Power

Supplies that are not current limited may cause the PowerStar to consume current above the specified maximum and

cause failure or irreparable damage.

z PowerStars, when operated, can reach high temperatures thus there is risk of injury if they are touched.

z DO NOT HOT PLUG ON LED SIDE OF POWER SUPPLY.

z DO NOT TOUCH or PUSH on the LED as this can cause irreparable damage.

Product Options

ILS PART NUMBER

Colour

Typical Wattage §

at 700mA

Forward

Voltage

Flux †

at 700mA

Radiance

Angle

Relevant OS-

RAM LED Data

ILH-OU01-HW90-SC221-WIR200.

Hot White

(2700K)

1.96W

2.7-3.2V

190lm

120° (±60°)

GWCSSRMU.

CM

ILH-OU01-WM90-SC221-WIR200.

Warm White

(3000K)

1.96W

2.7-3.2V

200lm

120° (±60°)

GWCSSRMU.

CM

ILH-OU01-QW90-SC221-WIR200.

Quartz White

(3500K)

1.96W

2.7-3.2V

210lm

120° (±60°)

GWCSSRMU.

CM

ILH-OU01-NW90-SC221-WIR200.

Neutral White

(4000K)

1.96W

2.7-3.2V

220lm

120° (±60°)

GWCSSRMU.

CM

*Due to the special conditions of the manufacturing processes of LEDs, the typical data of technical parameters can only reflect statistical figures and do not

necessarily correspond to the actual parameters of each single product which could differ from the typical data.

§ Tolerance +/- 10%

† Measured with 20mS 700mA pulse at 85˚C

Minimum and Maximum Ratings

ILS PART NUMBER

Operating

Temperature at

Tc-Point [˚C]*

Storage

Temperature [˚C]*

Forward Current

per chip [mA]*

Reverse Voltage [Vdc]*

ILH-OU01-HW90-SC221-WIR200.

-40 ... 125 (°C)

-40 ... 125 (°C)

200mA ... 1800mA

Not designed for reverse

voltage

ILH-OU01-WM90-SC221-WIR200.

-40 ... 125 (°C)

-40 ... 125 (°C)

200mA ... 1800mA

Not designed for reverse

voltage

ILH-OU01-QW90-SC221-WIR200.

-40 ... 125 (°C)

-40 ... 125 (°C)

200mA ... 1800mA

Not designed for reverse

voltage

ILH-OU01-NW90-SC221-WIR200.

-40 ... 125 (°C)

-40 ... 125 (°C)

200mA ... 1800mA

Not designed for reverse

voltage

* Exceeding maximum ratings for operating and storage temperature will reduce expected life time or destroy the LED module. Exceeding maximum ratings for

operating voltage will cause hazardous overload and will likely destroy the LED module. The temperature of the LED module must be measured at the Tc-Point

according to EN60598-1 in a thermally constant status with a temperature sensor or a temperature sensitive label.
