E5ED/E5ED-B

21

Model Number Legend and Standard Models

Model Number Legend

Models with Screw Terminal Blocks

E5ED-

@@ 4 @ 6M -@@@

(Example: E5ED-RX4A6M-000)

−− − − − − −−−

AB C D E

F

Heating and Cooling Control

Using Heating and Cooling Control

A Control Output Assignment

If there is no control output 2, an auxiliary output is used as the cooling control output.

If there is a control output 2, the two control outputs are used for heating and cooling. (It does not matter which output is used for heating and which

output is used for cooling.)

B Control

If PID control is used, you can set PID control separately for heating and cooling.

This allows you to handle control systems with different heating and cooling response characteristics.

List of Models

Model

A

B

C

D

E

F

Meaning

Control outputs

1 and 2

No. of

auxiliary

outputs

Power

supply

voltage

Terminal

type

Input

type

Options

E5ED

48

× 96 mm

Control output 1

Control output 2

RX

Relay output

None

QX

Voltage output (for driving SSR)

None

CX

Linear current output

None

QR

Voltage output (for driving SSR)

Relay output

RR

Relay output

Relay output

4

4 (auxiliary outputs 1 and 2 with same common and

auxiliary outputs 3 and 4 with same common)

A

100 to 240 VAC

D

24 VAC/DC

6

Screw terminal blocks (with E53-COV24 Terminal

Cover), draw-out structure

M

Universal input

HB alarm and

HS alarm

Communications Event

inputs

Transfer

Output

000

---

---

---

---

*1

004

---

RS-485

2

---

*2

008

1

RS-485

2

---

*3

010

1

---

4

---

*1

022

---

RS-485

4

Provided.

*1. This option can be selected when the control output is CX.

*2. This option can be selected when the control output is RX, QX, QR, or RR.

*3. This option can be selected when the control output is RX or QX.

Model

Model

E5ED-RX4A6M-000

E5ED-CX4A6M-000

E5ED-RX4D6M-000

E5ED-CX4D6M-000

E5ED-RX4A6M-008

E5ED-CX4A6M-004

E5ED-RX4D6M-008

E5ED-CX4D6M-004

E5ED-RX4A6M-010

E5ED-CX4A6M-022

E5ED-RX4D6M-010

E5ED-CX4D6M-022

E5ED-QX4A6M-000

E5ED-RR4A6M-000

E5ED-QX4D6M-000

E5ED-RR4A6M-008

E5ED-QX4A6M-008

E5ED-QR4A6M-000

E5ED-QX4D6M-008

E5ED-QR4A6M-008

E5ED-QX4A6M-010

E5ED-QX4D6M-010
