KW EELP41.RU

DATASHEET

2 | Version 1.2 | 2025-07-10

SMARTLED™ 0603

KW EELP41.RU

The SMARTLED™ 0603 is the product of choice for status indi-

cation and symbol backlighting in electronics.

The small package size allows compact designs. The improved

corrosion robustness and increased junction temperature range

makes the devices from this series suitable for professional

industrial equipment and applications.

Applications

- Appliances & Tools

- Display Backlighting

- Factory Automation

- Home & Building Automation

- Projection & Display

- Static Signaling

- Transportation

Features

- Package: SMT package 0603, colored diffused resin

- Chip technology: Volume emitter on Sapphire (AlInGaN)

- Typ. Radiation: 130° (horizontal = 0°), 150° (vertical = 90°)

- Color: Cx = 0.3, Cy = 0.29 acc. to CIE 1931 (● white)

- Corrosion Robustness Class: 3B

- ESD: 8 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM, Class 3B)
