Specifications

Electrical Specifications

Frequency

2360-2500 MHz

Gain

8.5 dBi

Impedance

50 Ohm

VSWR

< 2.0:1 avg.

Maximum Input Power

100 W

Mechanical Specifications

Polarization

Vertical

Vertical Beam Width

15°

Horizontal Beam Width

360°

Weight

1.5 lbs. (.68 kg)

Length

21 in. (533 mm)

Base Diameter

2.6 in. (66.8 mm)

Radome Material

Gray Fiberglass

Wind Survival

>150 MPH

Operating Temperature

-40° C to 85° C

(-40° F to 185° F)

RoHS Compliant

Yes

Mounting

Magnetic Base

Antenna Connector

Integral N-Male

Antenna Gain Pattern

Guaranteed Quality

This product is backed by L-Com's Limited Warranty
