Table3 APM32F103xB Pin Function Description

Pin Name

Pin No.

Type

(1)

Main function (3)

Optional multiplexing function

(After reset)

Default

multiplexing

function

Redefining

function

PE2

I/O

PE2

TRACECK

PE3

I/O

PE3

TRACED0

PE4

I/O

PE4

TRACED1

PE5

I/O

PE5

TRACED2

PE6

I/O

PE6

TRACED3

VBAT

PC13-

TAMPER-RTC(4)

I/O

PC13(3)

TAMPER-RTC

PC14-

OSC32_IN(4)

I/O

PC14(3)

OSC32_IN

PC15-

OSC32_OUT(4)

I/O

PC15(3)

OSC32_OUT

VSS_5

VDD_5

OSC_IN

PD0(5)

OSC_OUT

PD1(5)

NRST

I/O

NRST

PC0

I/O

PC0

ADC12_IN10

PC1

I/O

PC1

ADC12_IN11

PC2

I/O

PC2

ADC12_IN12

PC3

I/O

PC3

ADC12_IN13

VSSA

VREF-

VREF+

VDDA

PA0-WKUP

I/O

PA0

WKUP/

USART2_CTS(6)/

ADC12_IN0/

TMR2_CH1_ETR(6)

PA1

I/O

PA1

USART2_RTS(6)/

ADC12_IN1/

TMR2_CH2(6)
