15 / 18 page ![]() Data Sheet ADRF5440 APPLICATIONS INFORMATION analog.com Rev. A | 15 of 18 The ADRF5440 has two power supply pins (VDD and VSS) and two digital control pins (V1 and V2). Figure 25 shows the external components and connections for the supply pins. The VDD, VSS, V1, and V2 pins are decoupled with a 100pF multilayer ceramic capacitor. The device pinout allows the placement of the decoupling capacitors close to the device. No other external components are needed for bias and operation, except DC blocking capacitors on the RFx pins when the RF lines are biased at a voltage different than 0V. Refer to the Pin Configuration and Function Descriptions section for further details. Figure 25. Recommended Schematic |
|
|
