VS = ±5 V, @ TA = 25°C, VO = 1.4 V p-p, G = ×2, RL = 150 Ω, unless otherwise noted.

Table 2.

Parameter

Test Conditions/Comments

Min

Typ

Max

Unit

OVERALL PERFORMANCE

Offset Error

Input referred, all channels except CV

14

33.5

mV

Input referred, CV

15

42.5

mV

Max Voltage Across LEVEL1 and LEVEL2 Inputs

±500

mV

Input Voltage Range, All Inputs

VS− − 0.1

VS+ − 2.0

V

Output Voltage Swing, All Outputs

Positive swing

VS+ − 0.35

VS+ − 0.25

V

Negative swing

VS− + 0.3

VS− + 0.5

V

Linear Output Current per Channel

30

mA

Integrated Voltage Noise, Referred to Input

All channels except CV

500

µVrms

Filter Input Bias Current

All channels

6.3

15

µA

Total Harmonic Distortion at 1 MHz

FC = 36 MHz, FC = 18 MHz/FC = 9 MHz

0.01/0.07

%

RGB/YPbPr CHANNEL DYNAMIC PERFORMANCE

−1 dB Bandwidth

Cutoff frequency select = 36 MHz

29

MHz

Cutoff frequency select = 18 MHz

15

MHz

Cutoff frequency select = 9 MHz

8

MHz

−3 dB Bandwidth

Cutoff frequency select = 36 MHz

33.0

35.5

MHz

Cutoff frequency select = 18 MHz

16.5

18

MHz

Cutoff frequency select = 9 MHz

8

9.5

MHz

Out-of-Band Rejection

f = 75 MHz

−33

−41.5

dB

Crosstalk

f = 5 MHz, FC = 36 MHz

−68

dB

Input Mux Isolation

f = 1 MHz, RSOURCE = 300 Ω

86

dB

Propagation Delay

f = 5 MHz, FC = 36 MHz

21

ns

Group Delay Variation

Cutoff frequency select = 36 MHz

7.5

ns

Cutoff frequency select = 18 MHz

14

ns

Cutoff frequency select = 9 MHz

26

ns

Y/C SD CHANNEL DYNAMIC PERFORMANCE

−1 dB Bandwidth

7.5

MHz

−3 dB Bandwidth

8

9

MHz

Out-of-Band Rejection

f = 27 MHz

−57

dB

Propagation Delay

f = 1 MHz

64

ns

Group Delay Variation

26

ns

Crosstalk

f = 1 MHz

−72

dB

Input Mux Isolation

f = 1 MHz, RSOURCE = 75 Ω

77

dB

Y/C, CV OUTPUT VIDEO PERFORMANCE

Differential Gain

NTSC

0.11

%

Differential Phase

NTSC

0.25

Degrees

CONTROL INPUT PERFORMANCE

Input Logic 0 Voltage

All inputs except DISABLE

0.8

V

Input Logic 1 Voltage

All inputs except DISABLE

2.0

V

Input Bias Current

All inputs except DISABLE

7

15

µA

DISABLE PERFORMANCE

DISABLE Assert Voltage

VS+ − 0.5

V

DISABLE Assert Time

75

ns

DISABLE Deassert Time

125

ns

DISABLE Input Bias Current

35

45

µA

Input-to-Output Isolation—Disabled

100

dB
