6 / 24 page

OP113/OP213/OP413

Rev. F | Page 6 of 24

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

±18 V

Input Voltage

±18 V

Differential Input Voltage

±10 V

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +85°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature Range (Soldering, 60 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

Table 4. Thermal Resistance

Package Type

θJA

θJC

Unit

8-Lead PDIP (P)

103

°C/W

8-Lead SOIC_N (S)

158

°C/W

16-Lead SOIC_W (S)

°C/W

ESD CAUTION
