ADM1191

Rev. B | Page 5 of 16

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

VCC Pin

30 V

SENSE Pin

30 V

CONV Pin

−0.3 V to +6 V

SETV Pin

30 V

ALERTB Pin

30 V

SDA Pin, SCL Pin

−0.3 V to +6 V

A0 Pin, A1 Pin

−0.3 V to +6 V

Storage Temperature Range

−65°C to +125°C

Operating Temperature Range

−40°C to +85°C

Lead Temperature (Soldering, 10 sec)

300°C

Junction Temperature

150°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL CHARACTERISTICS

soldered in a circuit board for surface-mount packages.

Table 3. Thermal Resistance

Package Type

Unit

10-Lead MSOP

137.5

°C/W

ESD CAUTION
