44 / 66 page ![]() Data Sheet ADAR4002 THEORY OF OPERATION analog.com Rev. A | 44 of 66 zero padding bits can be eliminated from the SPI transaction to reduce data transfer time. Note that any changes in these streamwrite registers also change the corresponding data in the regular TDU and DSA data registers (Register 0x20 through Register 0x5F), and vice versa. Also note that the data is arranged in an ascending address block write. Bit 5 and Bit 2 must be asserted high in Register 0x000 for address ascension. Register 0xF0 and Register 0xF1 The current time delay and DSA values being applied to the TDU and DSA blocks can be read back from Registers 0xF0 and Register 0xF1. |
|
