14 / 197 page  IS25LE256E/128E IS25WE256E/128E Integrated Silicon Solution, Inc.- www.issi.com 14 Rev.A9 03/07/2023 5. SYSTEM CONFIGURATION The memory array is divided into uniform 4 Kbyte sectors or uniform 32/64 Kbyte blocks (a block consists of eight/sixteen adjacent sectors respectively). Also optional uniform 32/256 Kbyte blocks are available with 512B page size. See ordering table for more detail information. Table 5.1 illustrates the memory map of the device. The Status Register controls how the memory is protected. 5.1 BLOCK/SECTOR ADDRESSES Table 5.1 Block/Sector Addresses (Block Size = 32KB/64KB) Memory Density Block No. (64Kbyte) Block No. (32Kbyte) Sector No. Sector Size (Kbyte) Address Range Block 0 Block 0 Sector 0 4 000000h - 000FFFh : : : Block 1 : : : Sector 15 4 00F000h - 00FFFFh Block 1 Block 2 Sector 16 4 010000h - 010FFFh : : : Block 3 : : : Sector 31 4 01F000h - 01FFFFh Block 2 Block 4 Sector 32 4 020000h - 020FFFh : : : Block 5 : : : Sector 47 4 02F000h - 02FFFFh : : : : : Block 254 Block 508 Sector 4064 4 FE0000h – FE0FFFh : : : Block 509 : : : Sector 4079 4 FEF000h – FEFFFFh Block 255 Block 510 Sector 4080 4 FF0000h – FF0FFFh : : : Block 511 : : : Sector 4095 4 FFF000h – FFFFFFh : : : : : Block 510 Block 1020 Sector 8160 4 1FE0000h – 1FE0FFFh : : : Block 1021 : : : Sector 8175 4 1FEF000h – 1FEFFFFh Block 511 Block 1022 Sector 8176 4 1FF0000h – 1FF0FFFh : : : Block 1023 : : : Sector 8191 4 1FFF000h – 1FFFFFFh |
|
