Antenna

A range of high quality antennae designed and manufactured for operation specifically with Low power short

range telemetry systems. Using one of the following antennae will give optimum range and reliability to your

application.

‘Stubby’ Helical Antenna

•

1/

4 Wavelength Helical Antenna

•

Rugged Plastic Finish, Flexible Antenna

•

Available As BNC, 4BA, M4 Screw Fixing

1/

4 Wave Flexible Antenna

•

Standard

1/

4 Wavelength Whip Antenna

•

Rugged Plastic Finish. Flexible Antenna

•

Available as BNC, 4BA, M4 Screw Fixing

•

Available as Straight or Right Angle

+3db GAIN ANTENNA

•

+3db GAIN

5/

8 Wavelength Whip Antenna

•

Integral Wall Mounting Bracket

•

Supplied With 2 Metres Coax Cable & BNC (50

Ω)

Note: In Order To Comply With The UK DTI Regulations, A Gain

Antenna Must Not Be Used On Any Transmitting Device.
