HEADER SHAPE

FOOT PRINT

MOUNTING PAD LAYOUT

RECOMMENDED

SHIPPING TUBE

DIMENSIONS (mm)

TYP

A

B

C

Length tube

18

12

0,8

532

Quantity per tube

50

Dimensions in millimeters

Dimensions in millimeters
