www.ti.com

PACKAGE OUTLINE

C

TYP

8.3

7.9

1.2 MAX

54X 0.5

56X 0.27

0.17

2X

13.5

(0.15) TYP

0 - 8

0.15

0.05

0.25

GAGE PLANE

0.75

0.50

A

NOTE 3

14.1

13.9

B

6.2

6.0

4222167/A 07/2015

TSSOP - 1.2 mm max height

DGG0056A

SMALL OUTLINE PACKAGE

NOTES:

1. All linear dimensions are in millimeters. Any dimensions in parenthesis are for reference only. Dimensioning and tolerancing

per ASME Y14.5M.

2. This drawing is subject to change without notice.

3. This dimension does not include mold flash, protrusions, or gate burrs. Mold flash, protrusions, or gate burrs shall not

exceed 0.15 mm per side.

4. Reference JEDEC registration MO-153.

1

56

0.08

C A

B

29

28

PIN 1 ID

AREA

SEATING PLANE

0.1 C

SEE DETAIL A

DETAIL A

TYPICAL

SCALE 1.200
