Type: CDH20D10

Please refer to the sales offices on our website for a representative near you

www.sumida.com

2/2

Power Inductors <SMD Type: CDH Series>

B: Box

C: Carrier Tape

◆

Specification

Part Name

※

Stamp

Inductance

(μH)

100kHz/1V

D.C.R.(Ω)

Max.(Typ.)

(at 20℃)

Saturation

Current

（

A）※1

Temperature

Rise Current

(A) ※2

CDH20D10NP-R50M□

A

0.5±20％

83m(66m)

2.01(2.52)

1.65(1.84)

CDH20D10NP-R68M□

B

0.68±20％

94m(75m)

1.75(2.19)

1.47(1.68)

CDH20D10NP-R80M□

C

0.8±20％

104m(83m)

1.63(2.04)

1.43(1.62)

CDH20D10NP-1R0M□

D

1.0±20％

0.139(0.111)

1.45(1.82)

1.18(1.34)

CDH20D10NP-1R2M□

E

1.2±20％

0.158(0.126)

1.44(1.80)

1.16(1.32)

CDH20D10NP-1R5M□

F

1.5±20％

0.173(0.138)

1.27(1.59)

1.08(1.22)

CDH20D10NP-1R8M□

G

1.8±20％

0.235(0.188)

1.08(1.36)

0.90(1.02)

CDH20D10NP-2R0M□

J

2.0±20％

0.252(0.201)

1.04(1.30)

0.88(1.01)

CDH20D10NP-2R2M□

K

2.2±20％

0.276(0.221)

1.00(1.26)

0.87(0.98)

CDH20D10NP-2R7M□

L

2.7±20％

0.370(0.295)

0.89(1.12)

0.74(0.82)

CDH20D10NP-3R3M□

M

3.3±20％

0.425(0.339)

0.81(1.02)

0.70(0.79)

CDH20D10NP-3R9M□

P

3.9±20％

0.463(0.370)

0.72(0.92)

0.58(0.65)

CDH20D10NP-4R7M□

R

4.7±20％

0.53(0.42)

0.70(0.87)

0.53(0.61)

CDH20D10NP-5R6M□

T

5.6±20％

0.75(0.60)

0.63(0.79)

0.49(0.55)

※

Description of part name

CDH20D10NP-R50M□

※

1. Saturation Current: The DC current at which the inductance decreases to 90% of its nominal value.

※

2. Temperature Rise Current: The DC current at which the temperature rise is △t＝40℃ (Ta＝20℃) .
