1 / 2 page

FF0829SA1-R3000

Features

FPC connector, ZIF (Zero Insertion Force) type, 29 pos., 0.2 mm pitch, 1 mm height , Standard mounting type

Part Number

FF0829SA1-R3000

Status

Pending Obsolescence

Number of Positions

29 pos.

Contact Pitch (mm)

0.2 mm

Rated Current (A)

0.3 A

Connector Type

Standard mounting type

PCB Mounted Height (mm)

1

FPC Entry Angle

Right-angle (Lower-side contact)

ZIF/ Non-ZIF/ LIF

ZIF

Applicable FPC Thickness

(mm)

0.15 ± 0.02

Mounting Method

Soldering (SMT)

Staggered Pattern

Applicable

Material of Contact

Copper alloy

Finish of Contact in Connecting

Area

Partial Gold plating over Nickel

Material of Housing

Heat resisting plastics

Product Details
