CC1000

SWRS048A

Page 4 of 55

1. Absolute Maximum Ratings

Parameter

Min.

Max.

Units

Condition

Supply voltage, VDD

-0.3

5.0

Voltage on any pin

-0.3

VDD+0.3,

max 5.0

Input RF level

dBm

Storage temperature range

(TSSOP)

-50

150

°C

Shelf life (UltraCSP™)

year

Room temperature and oxygen

free cabinet

Reflow soldering temperature

(TSSOP)

260

°C

IPC/JEDEC J-STD-020C

Peak reflow soldering temperature

(UltraCSP™)

255

°C

IPC/JEDEC J-STD-020C

Under no circumstances the absolute

maximum ratings given above should be

violated. Stress exceeding one or more of

the limiting values may cause permanent

damage to the device.

Caution! ESD sensitive device.

Precaution should be used when handling

the device in order to prevent permanent

damage.

2. Operating Conditions

Parameter

Min.

Typ.

Max.

Unit

Condition / Note

RF Frequency Range

300

1000

MHz

Programmable in steps of 250 Hz

Operating ambient temperature range

-40

°C

Supply voltage

2.1

3.0

3.6

Note: The same supply voltage

should be used for digital (DVDD)

and analogue (AVDD) power.

3. Electrical Specifications

Tc = 25

°C, VDD = 3.0 V if nothing else stated

Parameter

Min.

Typ.

Max.

Unit

Condition / Note

Transmit Section

Transmit data rate

0.6

76.8

kBaud

NRZ or Manchester encoding.

76.8 kBaud equals 76.8 kbit/s

using NRZ coding. See page 16.

Binary FSK frequency separation

kHz

The frequency separation is

programmable in 250 Hz steps.

65 kHz is the maximum

guaranteed separation at 1 MHz

reference frequency. Larger

separations can be achieved at

higher reference frequencies.
