CC1070
SWRS043A
Page 52 of 54
25 Package Marking
When contacting technical support with a chip-related question, please state the entire marking
information as stated below (this is for RGW package).
o – pin one symbolization
TI – TI letters
YM – Year Month Date Code
SLLLL – Assembly Lot Code
G4 – fixed code
25.1 Soldering Information
The recommendation for lead-free reflow in IPC/JEDEC J-STD-020 should be followed.
25.2 Tray Specification
QFN 5x5 mm standard shipping tray.
Tray Specification
Package
Tray Width
Tray Height
Tray Length
Units per Tray
QFN 20 (RSQ)
135.9 mm
7.62 mm
315 mm
490
25.3 Carrier Tape and Reel Specification
Carrier tape and reel is in accordance with EIA Specification 481.
Tape and Reel Specification
Package
Tape Width
Component
Pitch
Hole
Pitch
Reel
Diameter
Units per Reel
QFN 20 (RSQR)
12 mm
8 mm
4 mm
13”
5000
CC1070
TI YMS
LLLL G4
