ams Datasheet

Page 1

[v1-07] 2015-Feb-27

Document Feedback

AS5510

Linear Hall Sensor with I²C Output

The AS5510 is a Linear Hall Sensor with 10 bit resolution and I²C

interface. It can measure absolute position of lateral movement

of a simple 2-pole magnet. Depending on the magnet size, a

lateral stroke of 0.5~2mm can be measured with air gaps

around 1.0mm. To conserve power, the AS5510 may be

switched to a power down state when it is not used. It is

available in a WLCSP and SOIC8 package and qualified for an

ambient temperature range from -30°C to 85°C.

Ordering Information and Content Guide appear at end of

datasheet.

Key Benefits & Features

The benefits and features of AS5510, Linear Hall sensor with I²C

output are listed below:

Figure 1:

Added Value of Using AS5510

Applications

The AS5510 is ideal for:

• Position sensing

• Servo drive feedback

• Camera lens control

• Closed loop position control.

Benefits

Features

Highest reliability and durability

Contactless position measurement

Ideal for battery powered devices

Power down mode

Easy to use

Simple configuration over the I2C interface

High-resolution output

10bit resolution

Operates in wide magnetic range

Programmable sensitivity

Smallest form factor

Available in two different packages: WLCSP & SOIC8

General Description
