MAY OCCUR

A

B

C

D

COLOR VARIATIONS

CONFIGURATION DETAILS OF

01845

SCALE:

SIZE

CAD FILE:

DWG. NO.

A

SHEET

OF

REV.

DATE

APPROVALS

DRAWN BY

CHECKED BY

APPROVED BY

1

2

3

4

5

6

7

8

NORTH ANDOVER, MA

45 BEECHWOOD DRIVE

WITHOUT THE WRITTEN PERMISSION OF L-COM, INC. IS PROHIBITED.

A

B

C

D

1

2

3

4

5

6

7

8

CA-RSPNMB

A

CA-RSPNMB.SLDDRW

11

REVISIONS

DESCRIPTION

APPROVED

REV

DATE

CATEGORY

PRODUCT DESCRIPTION

DIMENSIONS ARE IN INCHES [mm]

PROPERTY OF L-COM, INC. ANY REPRODUCTION IN PART OR WHOLE

THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE

MAY VARY

NONE

FSCM NO.

43321

PROJECTION

UNLESS OTHERWISE SPECIFIED,

UNDIMENSIONED FEATURES

OVERALL CABLE LENGTH TOLERANCE:

≤12 [305] = +1 [25] / -0

>12 [305] ≤60 [1524] = +2 [51] / -0

>60 [1524] ≤120 [3048] = +4 [102] / -0

>120 [3048] ≤300 [7620] = +6 [152] / -0

>300 [7620] = +5% / -0%

ALL OTHER DIMENSIONAL TOLERANCES:

.X = ± .2

.XX = ± .02

.XXX = ±.005

RP-SMA Plug To N-Male Assembly w/Heatshrink

02/11/10

2/11/10 B.Puchaski

A

M.Audas

M.Audas

B.Puchaski

02/11/10

02/11/10

Initial Release

Fabrication: White CA-195RW Series

COAXIAL

(1X) CA-195RW/50Ω

COAXIAL CABLE-WHITE

CA-RSPNMBXXX

N STRAIGHT MALE

CABLE# & LENGTH

CA-RSPNMBNXX

CA-RSPNMBMXX

WHERE XXX = LENGTH IN FEET

WHERE NXX = LENGTH IN INCHES

WHERE MXX = LENGTH IN METERS

WHERE XMX = LENGTH IN DECIMEL METERS

CA-RSPNMBXMX

CA-RSPNMB010 (10 FEET)

CA-RSPNMBN16 (16 INCHES)

CA-RSPNMBM07 (7 METERS)

CA-RSPNMB3M5 (3.5 METERS)

EXAMPLES OF PART# USED

LENGTH CODE CHART

LENGTH SYMBOL

CRIMP CONNECTOR

L-COM SPECIFICATION PS-0031

6. CENTER PIN OF CONNECTORS TO BE SOLDERED OR CRIMPED ONTO CABLE INNER CONDUCTOR

NOTES:

1. CABLE ASSEMBLY SHALL BE TESTED FOR CONTINUITY

2. CABLE ASSEMBLY SHALL RECIEVE INSERTION LOSS TEST#TP-00027

3. CABLE ASSEMBLY SHALL WITHSTAND PULL TEST OF 40lbs WITHOUT

ANY SEPERATION OR ELECTRICAL FAILURE

4. CABLE SHALL BE RoHS COMPLIANT

5. CABLE ASSEMBLY SHALL BE INDIVIDUALLY PACKAGED IN ACCORDANCE WITH

RP-SMA STRAIGHT PLUG

CRIMP CONNECTOR

(REF LENGTH CODE CHART)

-LENGTH-

1"(±.04)[25.4mm(±1.0)]

(2X) WHITE HEATSHRINK
