SE2582L

RangeCharger™ 2.4 GHz Power Amplifier with Power Detector

212-DST-01 Rev 1.2 Mar-27-2007

Confidential

3 of 8

QA032707

Absolute Maximum Ratings

These are stress ratings only. Exposure to stresses beyond these maximum ratings for a long period of time may

cause permanent damage to, or affect the reliability of the device. Avoid operating the device outside the

recommended operating conditions defined below. This device is ESD sensitive. Handling and assembly of this

device should be at ESD protected workstations.

Symbol

Definition

Min.

Max.

Unit

-0.3

4

V

Power Amplifier Enable

-0.3

4

V

-

10

dBm

Storage Temperature Range

-40

150

°C

Maximum Junction Temperature

-

150

°C

Recommended Operating Conditions

Symbol

Parameter

Min.

Max.

Unit

Supply Voltage

2.9

3.6

V

Ambient Temperature

-10

85

°C

DC Electrical Characteristics

unless otherwise noted.

Symbol

Parameter

Conditions

Min.

Typ.

Max.

Unit

Supply Current

signal, BT = 0.45,

-

134

-

mA

Supply Current

signal, 64 QAM

-

105

-

mA

Quiescent Current

No RF

-

48

-

mA

Supply Current

-

0.5

10

μA

Logic High Voltage

-

1.3

-

V

Logic Low Voltage

-

0

-

0.5

V
