TPS853

2007-10-01

1

TOSHIBA Photo-IC Silicon Epitaxial Planar

TPS853

Mobile Phones, PHS

Notebook PCs, PDAs

Video cameras, Digital Still Cameras

Other Equipment Requiring Luminosity Adjustment

The TPS853 is an ultra-compact surface-mount photo-IC for

illuminance sensors which incorporates a photodiode and current amp

circuit in a single chip.

The sensitivity is superior to that of a phototransistor, and exhibits

little variation.

It has spectral sensitivity closer to luminous efficiency and excellent output linearity.

This photo-IC can be used as the power-saving control for domestic appliances or for backlighting for displays in

cellular phones.

This device includes stand-by function which can reduce the power consumption of the system.

• Ultra-compact and light surface-mount package: 2.0 × 2.1 × 0.7 mm

• Excellent output linearity of illuminance

• Little fluctuation in light current and high level of sensitivity

: Light current variation width: ×1.67 (when light current classification is specified.)

: Little temperature fluctuation in light current

• Built-in luminous-efficiency correction function, reduced sensitivity variations due to various light sources

• Lead(Pb)-Free

Characteristics

Symbol

Rating

Unit

Supply voltage

−0.5 to 7

V

Output voltage

V

Stand-by voltage

V

Light current

5

mA

Permissible power dissipation

P

35

mW

Operating temperature range

−30 to 85

°C

Storage temperature range

−40 to 100

°C

Soldering temperature range (Note 1)

260

°C

Note: Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the

significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even

if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum

ratings and the operating ranges.

Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook

(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test

report and estimated failure rate, etc).

Note 1: The reflow time and the recommended temperature profile are shown in the section entitled Handling

Precautions.

Operating Ranges

Characteristics

Symbol

Min

Typ.

Max

Unit

Supply voltage

2.2

⎯

5.5

V

Stand-by voltage

Vstb

2.2

⎯

V

TOSHIBA

―

Weight: 0.0054 g (typ.)
