3.5”-SBC-RPL

Technical Information

Intel® Core™ i7-1365UE / i7-1365URE

(10C, 12M, 1.7 / 4.9 GHz, FCBGA1744, 12 W ← 15 W → 28 W TDP)

Intel® Core™ i5-1345UE / i5-1345URE

(10C, 12M, 1.4 / 4.6 GHz, FCBGA1744, 12 W ← 15 W → 28 W TDP)

Intel® Core™ i3-1315UE / i3-1315URE

(6C, 10M, 1.2 / 4.5 GHz, FCBGA1744, 12 W ← 15 W → 28 W TDP)

Intel® U300E

(5C, 8M, 1.1 / 4.3 GHz, FCBGA1744, 12 W ← 15 W → 28 W TDP)

2x DDR5 5200 SO-DIMM up to 96 GByte

Intel® Iris® Xe Graphics

1x eDP (4096 x 2304 @ 120 Hz) / LVDS (24-bit, 2-ch, 1920 x 1200 @ 60 Hz)

2x DP (7680 x 4320 @ 60 Hz, on rear)

Quadruple Display (more display I/Os supported via board-to-board connector)

TSI 92HD91B

1x Speaker-out (Stereo, 3 W, by header)

1x Line-in (by header)

1x Line-out (by header)

1x Mic-in (by header)

1x S/PDIF Out (by header)

2x 2.5 GbE LAN (RJ45 on rear, Intel® I226-LM/IT, TSN support*)

4x USB 3.2 Gen 2 (Type A on rear)

4x USB 2.0 (by header, -1 in case of 2x CAN Bus, -2 in case of 2x USB 2.0 in B2B)

2x RS232 (def.) / RS232/422/485 (opt.) (by header, Tx/Rx only for RS232 signal)

4x DI (by header)

4x DO (by header)

2x CAN Bus (optional, by header, trade o 1x USB 2.0 header)

1x SATA 3.0

1x M.2 Key B (Type 2242/3042/3052/2280, w/ PCIe x1 / USB 2.0 / SATA / UIM)

1x M.2 Key E (Type 2230, w/ PCIe x1 / USB 2.0 / CNVi)

1x M.2 Key M (Type 2280, w/ PCIe x4)

1x SIM Card Holder (by header)

1x DDI

1x TCP

1x PCIe x2

1x PCIe x1

1x SM Bus

1x I2C

1x UART

1x GSPI

2x USB 2.0 (optional, trade o 2x USB 2.0 header)

DC 9 V ~ 36 V (Configuration 1)

DC 12 V (Configuration 2)

1x4-pin pitch 3.0 mm Wafer

AMI uEFI BIOS w/ 256 Mb SPI Flash

Programmable WDT to generate system reset event

Voltages, Temperatures

Processor integrated RTC

TPM 2.0 Support (Infineon SLB 9672)

1x Header for Reset Button, HDD LED & External Speaker

1x Header for Power Button, Power LED & SM Bus

1x Standby LED (Yellow, on rear)

1x Power LED (Green, on rear)

1x Power Button (on rear)

1x Wafer for Smart Fan

Windows 11, Windows 10, Linux

ECX (146 mm x 105 mm / 5.75" x 4.13")

0 °C ~ 60 °C / 32 °F ~ 140 °F (Standard)

-40 °C ~ 85 °C / -40 °F ~ 185 °F (Extreme)

-20 °C ~ 80 °C / -4 °F ~ 176 °F (Standard)

-55 °C ~ 85 °C / -67 °F ~ 185 °F (Extreme)

0 % ~ 95 %

CE Class B, FCC Class B, ICES Class B, UKCA, UR (UL Recognized)

PROCESSOR

MEMORY

GRAPHICS

DISPLAY INTERFACE

MULTIPLE DISPLAY

AUDIO CODEC

AUDIO INTERFACE

ETHERNET

USB

SERIAL PORT

OTHER I/Os

SATA

M.2

SIM CARD HOLDER

BOARD-TO-BOARD CONNECTOR

INPUT VOLTAGE

CONNECTOR

BIOS

WATCHDOG

H/W MONITOR

REAL TIME CLOCK

SECURITY

FP HEADER

BUTTON, SWITCH & INDICATOR

FAN

OS SUPPORT

DIMENSION (L x W)

OPERATING TEMPERATURE

STORAGE TEMPERATURE

HUMIDITY

EMC & SAFETY

SYSTEM

VIDEO

AUDIO

NETWORK CONNECTION

PERIPHERAL CONNECTION

STORAGE & EXPANSION

POWER

FIRMWARE

SYSTEM CONTROL &

MONITORING

COOLING

SOFTWARE

MECHANICAL

ENVIRONMENTAL

COMPLIANCE

* TSN support only for models with Core™ URE Series processors
