MECHANICAL DRAWING

BLOCK DIAGRAM

Intel®

R680E/

Q670E

Chipset

Channel A

SATA 3.0

DDI

DDR5 4400MHz DIMM

SATA 4x

HDMI 2.0

DMI 4.0

LGA 1700

1G LAN 4

2.5G LAN 4

USB 3.2 Gen1 2x

2.5G LAN 2

USB 3.2 Gen2 2x

LAN I226V

USB 2.0

USB 2.0 Vertical Type A 1x

Channel A

DDR5 4400MHz DIMM

Channel B

DDR5 4400MHz DIMM

Channel B

DDR5 4400MHz DIMM

IT66318

DDI

DP++

VGA

PCIe 4.0 x4 / SATA 3.0

M.2 M key (NVMe)

PCIe 4.0 x4

PCIe 3.0 x4

USB 2.0

USB 3.2 Gen2/Gen1

USB 3.2 Gen1

PCIe 3.0

NC-SI

PCIe 3.0

2.5G LAN 3

USB 3.2 Gen1 2x

2.5G LAN 1

USB 3.2 Gen2 2x

USB 2.0

USB 3.2 Gen2/Gen1

USB 3.2 Gen1

PCIe 4.0 16x

PCIe x16 2x (1x16 or 2x8 signal)

PCIe

IT8893

PCI

DDI

DP to VGA

PCIe x4 2x

PCIe x4 1x

DDI

DP++

HDA

S/PDIF

Front Audio

Audio Jack

(Line-out/Mic-in/Line-in (opt.))

Realtek

ALC888

RS232/422/485 2x

RS232 4x

Super IO

with WDT

Fan Control

Case Open

H/W Monitor

PS/2 KB/MS

eSPI

PCIe 4.0 4x

PCIe x4

USB 3.2

USB 3.2 Gen1 2x

(Key B 20-pin)

USB 2.0

PCIe/CNVi

M.2 E Key

USB 2.0

SMBus

M.2 M Key (NVMe)

8 Bit DIO

SPI

SPI BIOS

TPM 2.0

eSPI

80 port Header

USB 2.0

MDI

LAN I226LM

LAN I226V

PCIe 3.0

MDI

LAN I210AT

OOB MDI Key A

Co-Lay

Q670E Only

R680E Only

USB 2.0 Vertical Type A 1x

USB 2.0 Header 2x
