TL061 - TL061A - TL061B

4/9

ELECTRICAL CHARACTERISTICS

VCC = ±15V, Tamb = +25°C (unless otherwise specified)

Symbol

Parameter

TL061AC, AI, AM

TL061BC, BI, BM

Unit

Min.

Typ.

Max.

Min.

Typ.

Max.

Vio

Input Offset Voltage (Rs = 50Ω)

Tamb = +25°C

Tmin ≤ Tamb ≤ Tmax

36

7.5

23

5

mV

DVio

Temperature Coefficient of Input Offset Voltage (Rs = 50Ω)

10

10

µV/°C

Iio

Input Offset Current - note 1)

Tamb = +25°C

Tmin ≤ Tamb ≤ Tmax

1.

The input bias currents of a FET-input operational amplifier are normal junction reverse currents, which are temperature sensitive.

Pulse techniques must be used that will maintain the junction temperature as close to the ambient temperature as possible.

5

100

3

5100

3

pA

nA

Iib

Input Bias Current -note 1

Tamb = +25°C

Tmin ≤ Tamb ≤ Tmax

30

200

7

30

200

7

pA

nA

Vicm

Input Common Mode Voltage Range

±11.5

+15

-12

±11

+15

-12

V

Vopp

Output Voltage Swing (RL = 10kΩ)

Tamb = +25°C

Tmin ≤ Tamb ≤ Tmax

20

20

27

20

20

27

V

Avd

Large Signal Voltage Gain

RL = 10kΩ, Vo = ±10V,

Tamb = +25°C

Tmin ≤ Tamb ≤ Tmax

4

4

64

4

6

V/mV

GBP

Gain Bandwidth Product

Tamb = +25°C, RL =10kΩ, CL = 100pF

11

MHz

Ri

Input Resistance

1012

1012

Ω

CMR

Common Mode Rejection Ratio

RS = 50Ω

80

86

80

86

dB

SVR

Supply Voltage Rejection Ratio

RS = 50Ω

80

95

80

95

dB

ICC

Supply Current, no load

Tamb = +25°C, no load, no signal

200

250

200

250

µA

PD

Total Power Consumption

Tamb = +25°C, no load, no signal

6

7.5

6

7.5

mW

SR

Slew Rate

Vi = 10V, RL = 10kΩ, CL = 100pF, Av = 1

1.5

3.5

1.5

3.5

V/

µs

tr

Rise Time

Vi = 20mV, RL = 10kΩ, CL = 100pF, Av = 1

0.2

0.2

µs

Kov

Overshoot Factor (see figure 1)

Vi = 20mV, RL = 10kΩ, CL = 100pF, Av = 1

10

10

%

en

Equivalent Input Noise Voltage

RS = 100Ω, f = 1KHz

42

42

nV

Hz

------------
