628-009-010-059 datasheet(1/1 Pages) EDAC

tên linh kiện	628-009-010-059

Giải thích chi tiết về linh kiện	628 (Metal) Series,D-Sub Connectors \| .109"(2.77mm) Contact Spacing x .112" (2.84mm) Row Spacing \| Vertical \| Receptacle \| Metal Body

PDF	1 Pages

Scroll/Zoom	100%

nhà sản xuất	EDAC [EDAC, All Rights Reserved.]

Trang chủ	https://edac.net/

Logo

1 / 1 page

2.77

1.385

16.30

24.990

30.80 ±0.35

10°

6.0 ±0.35

10.7

NOTES:

MATERIAL:

HOUSING: THERMOPLASTIC POLYESTER, UL94V-0

SHELL: STEEL, NICKEL PLATED

TOLERANCE

UNLESS OTHERWISE

SPECIFIED

.XX

±0.13

.XXX

DRAWN:

CHECKED:

SW REFERENCE NO.:

PART NUMBER:

SCALE:

YOUR CONNECTION TO QUALITY & SERVICE

WITHOUT WRITTEN PERMISSION.

THESE DRAWINGS AND SPECIFICATIONS

ARE THE PROPERTY OF EDAC INC.,AND

SHALL NOT BE REPRODUCED,OR COPIED

OR USED AS THE BASIS FOR THE

MANUFACTURE OR SALE OF APPARATUS

TORONTO, ONTARIO

EDAC INC

CANADA

DO NOT MAKE MANUAL REVISIONS TO MASTER.

THIS IS A C.A.D. GENERATED DRAWING

AUG. 01/2018

SHEET

OF

628 ASSEMBLY

1:1

C.B

DATE:

1

ISSUE

ISSUE NUMBER

ORIGINAL

1

THIS SERIES FULLY CONFORMS TO

THE EUROPEAN UNION DIRECTIVES

2011/65/EU FOR RoHS COMPLIANCY.

COMPLIANT

628 SERIES D-SUB CONNECTOR

.X

±0.25

1

DRAWING NUMBER:

±0.10

628-009-010-048
