SPECIFICATIONS FOR LIQUID CRYSTAL DISPLAY MODULE
MODEL NO: 240128-06
Pacific Display Devices
03.07.2006
25
Bit Set/Reset
Code
Function
Operand
11110xxx
bit reset
---
11111xxx
bit set
---
1111x000
bit 0 (LSB)
---
1111x001
bit 1
---
1111x010
bit 2
---
1111x011
bit 3
---
1111x100
bit 4
---
1111x101
bit 5
---
1111x110
bit 6
---
1111x111
bit 7 (MSB)
---
This command is used to set or reset a bit of 1 byte is specified by address pointer. Plural bits in the 1 byte data cannot
be set/reset at a time. Please refer following flow chart.
BIT SET/RESET
END
STATUS CHECK 1
LOWER ADDRESS DATA
STATUS CHECK 1
UPPER ADDRESS DATA
STATUS CHECK 1
ADDRESS POINTER SET 24H
STATUS CHECK 1
WRITE DATA SET
STATUS CHECK 1
BIT SET (RESET)
