5 / 23 page ![]() Data Sheet ADPL44002 analog.com Rev. 0 5 of 23 (VIN = VOUT +1V or 2.7V, whichever is greater, VOUT = 5V, VEN = VIN, IOUT = 10mA, CIN = COUT = 2.2µF, CSS = OPEN, TA = 25°C for typical specifications, TJ = −40°C to +125°C for minimum/maximum specifications, unless otherwise noted.) PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS PRECISION EN INPUT Logic High ENHIGH 2.7V ≤ VIN ≤ 40V 1.15 1.22 1.30 V Logic Low ENLOW 2.7V ≤ VIN ≤ 40V 1.06 1.12 1.18 V Logic Hysteresis ENHYS 2.7V ≤ VIN ≤ 40V 100 mV Leakage Current IEN-LKG EN = VIN or GND, 2.7V ≤ VIN ≤ 40V 0.04 1 µA Delay Time tEN-DLY From EN rising from 0V to VIN to 0.1 × VOUT, 2.7V ≤ VIN ≤ 40V 80 μs Output Noise OUTNOISE 10Hz to 100kHz, all output voltage options 20 µVRMS Power Supply Rejection Ratio PSRR 1MHz, VIN = 7V, VOUT = 5V 40 dB 100kHz, VIN = 7V, VOUT = 5V 58 dB 10kHz, VIN = 7V, VOUT = 5V 78 dB 1 Based on an endpoint calculation using 100μA and 200mA loads. See Figure 6 for typical load regulation performance for loads less than 1mA. 2 Dropout voltage is defined as the input-to-output voltage differential when the input voltage is set to the nominal output voltage. Dropout applies only for output voltages above 2.7V. 3 Start-up time is defined as the time between the rising edge of EN to OUT being at 90% of its nominal value. 4 Current-limit threshold is defined as the current at which the output voltage drops to 90% of the specified typical value. For example, the current limit for a 5.0V output voltage is defined as the current that causes the output voltage to drop to 90% of 5.0V or 4.5V. Table 2. Input and Output Capacitance, Recommended Specifications PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS INPUT AND OUTPUT CAPACITANCE Minimum Capacitance1 CMIN TA = −40°C to +125°C 1.5 µF Capacitor Effective Series Resistance (ESR) RESR TA = −40°C to +125°C 0.001 0.3 Ω 1 The minimum input and output capacitance must be greater than 1.5μF over the full range of operating conditions. The full range of operating conditions in the application must be considered during device selection to ensure that the minimum capacitance specification is met. X7R and X5R type capacitors are recommended, while Y5V and Z5U capacitors are not recommended for use with any LDO. |
|
|
