Data Sheet

AD8661/AD8662/AD8664

Rev. E | Page 7 of 16

ABSOLUTE MAXIMUM RATINGS

Table 5.

Parameter

Rating

Supply Voltage

18 V

Input Voltage

−0.1 V to V

S

Differential Input Voltage

18 V

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−60°C to +150°C

Operating Temperature Range

R-8, RM-8, R-14, and RU-14

−40°C to +125°C

CP-8-13

−40°C to +85°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature, Soldering (60 sec)

300°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 6. Thermal Resistance

Package Type

θ

JA

θ

JC

Unit

8-Lead SOIC

121

43

°C/W

8-Lead LFCSP

751

181

°C/W

8-Lead MSOP

142

44

°C/W

14-Lead SOIC

88.2

56.3

°C/W

14-Lead TSSOP

114

23.3

°C/W

1 Exposed pad soldered to application board.

ESD CAUTION
