DDB-UJS-RS1-1

• DDB-UJS-R1

• DDB-UJS-R2

• DDB-UJS-S1

NOTE

1. All part number above comes in a quantity of 2000 units per reel.

2. Other luminious intensity groups are also available upon request.

3. Luminous intensity is measured with an accuracy of ± 11%.

4. Wavelength binning is carried for all units as per the wavelength-binning table. Only one wavelength group is allowed for each reel.

5. An optional Vf bining is also available upon request. Bining scheme is as per following table.

Part Ordering

Number

Chip Technology

/ Color

Viewing

Angle˚

Luminous Intensity @

IF = 20mA IV (mcd)

InGaN : DDx-xJx

Semiconductors

Innovating Illumination

InGaN

Blue, 470nm

120

112.5 - 224.0

112.5 - 140.0

140.0 - 180.0

180.0 - 224.0

07/05/2007 V12.0

3
