Data Sheet

ADA4004-1/ADA4004-2/ADA4004-4

Rev. H | Page 5 of 16

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Supply Voltage

±18 V or +36 V

Input Voltage

V− < VIN < V+

Differential Input Voltage

±600 mV

Differential Input Current

±5 mA

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering 60 sec)

300°C

Stresses at or abovethoselisted under Absolute Maximum

Ratings may cause permanent damageto the product. This is a

stress rating only; functionaloperation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditionsfor extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is specified with the device soldered on a circuit board with

its exposed paddlesolderedto a pad (if applicable)on a 4-layer

JEDEC standard printedcircuit board with zero airflow.

Table 5.

Package Type

θJA

θJC

Unit

230

92

°C/W

177

53

°C/W

155

45

°C/W

186

52

°C/W

115

36

°C/W

5-Lead SOT (RJ-5)

8-Lead SOIC (R-8), ADA4004-1

8-Lead SOIC (R-8), ADA4004-2

8-Lead MSOP (RM-8)

14-Lead SOIC_N (R-14)

16-Lead LFCSP_VQ (CP-16-4)

44

31.5

°C/W

ESD CAUTION
