Data Sheet

ADA4530-1

SPECIFICATIONS

analog.com

Rev. C | 6 of 52

Table 2. (Continued)

Parameter1

Symbol

Test Conditions/Comments

Min

Typ

Max

Unit

Total Harmonic Distortion + Noise

THD + N

AV = 1, f = 1 kHz, VIN = 2 V rms

Bandwidth = 90 kHz

0.0015

%

Bandwidth = 500 kHz

0.0025

%

GUARD BUFFER

Guard Offset Voltage2, 4, 5

VGOS

VCM = 1.5 V to 8.5 V

15

100

µV

VCM = 1.5 V to 8.5 V, 0°C < TA < 125°C

120

µV

VCM = 1.5 V to 8.5 V, −40°C < TA < 0°C

250

µV

VCM = 0.1 V to 8.5 V

150

µV

Guard Offset Voltage Drift2, 4

ΔVGOS/ΔT

0°C < TA < 125°C

0.18

1

µV/°C

−40°C < TA < 0°C

1.4

7

µV/°C

Output Impedance

ZGOUT

1

kΩ

Output Voltage Range

VGOS < 150 µV

0.1

8.5

V

−3 dB Bandwidth

f−3dBGUARD

VIN = 10 mV rms, CL = 10 pF

5.5

MHz

1 These specifications represent the performance for 10 V ± 10% power supplies. All specifications are measured at the 10 V supply voltage.

2 The maximum specifications at −40°C < TA < +85°C and −40°C < TA < 0°C are guaranteed from characterization.

3 RH is relative humidity (see the Humidity Effects section for more information).

4 These typical specifications are equal to the average plus the standard deviation of the distribution from characterization.

5 The guard offset voltage is the voltage difference between the guard output and the noninverting input.

15 V NOMINAL ELECTRICAL CHARACTERISTICS

VSY = 16 V, VCM = VSY/2, TA = 25°C, unless otherwise noted. Typical specifications are equal to the average of the distribution from

characterization, unless otherwise noted. Minimum and maximum specifications are tested in production, unless otherwise noted.

Table 3.

Parameter1

Symbol

Test Conditions/Comments

Min

Typ

Max

Unit

INPUT CHARACTERISTICS

Input Bias Current2, 3

IB

RH < 50%

<1

±20

fA

−40°C < TA < +85°C, RH < 50%

±20

fA

−40°C < TA < +125°C, RH < 50%

±250

fA

Input Offset Current

IOS

RH < 50%

<1

±20

fA

−40°C < TA < +125°C, RH < 50%

±150

fA

Input Offset Voltage2, 4

VOS

+8

±40

µV

VCM = 1.5 V to 14.5 V

+9

±50

µV

VCM = 1.5 V to 14.5 V, 0°C < TA < 125°C

±70

µV

VCM = 1.5 V to 14.5 V, −40°C < TA < 0°C

±150

µV

VCM = 0 V to 14.5 V

±300

µV

Offset Voltage Drift2, 4

ΔVOS/ΔT

0°C < TA < 125°C

+0.13

±0.5

µV/°C

−40°C < TA < 0°C

−0.7

±2.8

µV/°C

Input Voltage Range

IVR

0

14.5

V

Common-Mode Rejection Ratio

CMRR

VCM = 1.5 V to 14.5 V

110

114

dB

−40°C < TA < +125°C

105

dB

VCM = 0 V to 14.5 V

93

dB

Large Signal Voltage Gain

AVO

RL = 2 kΩ to VCM, VOUT = 0.5 V to 15.5 V

130

155

dB

−40°C < TA < +125°C

125

dB

Input Resistance

RIN

−40°C < TA < +125°C

>100

TΩ

Input Capacitance

CIN

8
