19 / 36 page ![]() © 2005 Microchip Technology Inc. DS21949B-page 19 TC1303A/TC1303B/TC1303C/TC1304 3.9 Buck Regulator Input Voltage Pin (VIN1) VIN1 is the buck regulator power input supply pin. Connect a variable input voltage source to VIN1. Connect VIN1 and VIN2 together with board traces as short as possible. 3.10 Buck Inductor Output Pin (LX) Connect LX directly to the buck inductor. This pin carries large signal-level current; all connections should be made as short as possible. 3.11 Power Ground Pin (PGND) Connect all large-signal level ground returns to PGND. These large-signal, level ground traces should have a small loop area and length to prevent coupling of switching noise to sensitive traces. Please see the physical layout information supplied in Section 5.0 “Application Circuits/Issues” for grounding recommendations. 3.12 Exposed Pad (EP) For the DFN package, connect the EP to AGND, with vias into the AGND plane. |
|
